3D printer Delta SimT1

           Description:

               The Delta SimT1 is our company's latest small DIY model 3 d printers, suitable for printing of any shape model.

Printing:

Ÿ  Print technology: Fused Deposition Modeling(FDM)

Ÿ  Layer resolution: standard: 0.1 mm (maximum: 0.3 mm - minimum: 0.1 mm)

Ÿ  Build volume: 140 x 140 x 250 mm

Ÿ  Print speed: 10 mm/s - 100 mm/s

Ÿ  Filament diameter: 1.75 mm

Ÿ  Prints: PLA, ABS
Testing with other materials in progress.

Ÿ  Nozzle diameter: 0.4mm

Ÿ  Maximum nozzle operating temperature: 260 °C

software:

Ÿ  Firmware: Modified Open Source Marlin 3D Printer
Firmware - user upgradable

Ÿ  software: Repetier - CuraEngine - Slic3r
(RepRap compatible)

Hardware:

Ÿ  Dimensions: 35*31*63cm(not includes Material)

Ÿ  Packing Dimensions: 67cm×37cm×17.5cm

Ÿ  Frame: Polycarbonate panels and fiber reinforced molded ABS parts

Ÿ  weight: 8.7 kg

Ÿ  ambient operation temperature: max 25 °C

Ÿ  storage temperature: - 10 °C to + 40 °C

Electrical:

Ÿ  Communication: USB 2.0 or SD card

Ÿ  Controller board: AVR ATmega2560 based

Ÿ  Display: 4 x 20 char. blue LCD with white backlight

Ÿ  AC input: 100 - 240 VAC 50-60Hz 150W max.
